Intel Core I7-12700 Processor 25MB Cache, 3.60 GHz Up To 4.90 GHz (20 Threads, 12 Cores)

Intel Core I7-12700 Processor 25MB Cache, 3.60 GHz Up To 4.90 GHz (20 Threads, 12 Cores)

132,000/=

Availability: In Stock

Brand: Intel

Product Code: intel

Tags: Intel Core I7-12700 Processor 25MB Cache, 3.60 GHz Up To 4.90 GHz (20 Threads, 12 Cores)

Qty:

Description
Reviews (0)

DESCRIPTION :

Processor Number		i7-12700

Status		Launched

Launch Date		Q1'22

Lithography		Intel 7

Use Conditions		PC/Client/Tablet

CPU Specifications

Total Cores		12

# of Performance-cores		8

# of Efficient-cores		4

Total Threads		20

Max Turbo Frequency		4.90 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency ‡		4.90 GHz

Performance-core Max Turbo Frequency		4.80 GHz

Efficient-core Max Turbo Frequency		3.60 GHz

Performance-core Base Frequency		2.10 GHz

Efficient-core Base Frequency		1.60 GHz

Cache		25 MB Intel® Smart Cache

Total L2 Cache		12 MB

Processor Base Power		65 W

Maximum Turbo Power		180 W

Supplemental Information

Embedded Options Available		Yes

Datasheet		View now

Memory Specifications

Max Memory Size (dependent on memory type)		128 GB

Memory Types		Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s

Max # of Memory Channels		2

Max Memory Bandwidth		76.8 GB/s

ECC Memory Supported ‡		Yes

Processor Graphics

Processor Graphics ‡		Intel® UHD Graphics 770

Graphics Base Frequency		300 MHz

Graphics Max Dynamic Frequency		1.50 GHz

Graphics Output		eDP 1.4b \| DP 1.4a \| HDMI 2.1

Execution Units		32

Max Resolution (HDMI)‡		4096 x 2160 @ 60Hz

Max Resolution (DP)‡		7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel)‡		5120 x 3200 @ 120Hz

DirectX* Support		12

OpenGL* Support		4.5

Multi-Format Codec Engines		2

Intel® Quick Sync Video		Yes

Intel® Clear Video HD Technology		Yes

# of Displays Supported ‡		4

Device ID		0x4680

OpenCL* Support		2.1

Expansion Options

Direct Media Interface (DMI) Revision		4

Max # of DMI Lanes		8

Scalability		1S Only

PCI Express Revision		5.0 and 4.0

PCI Express Configurations ‡		Up to 1x16+4 \| 2x8+4

Max # of PCI Express Lanes		20

Package Specifications

Sockets Supported		FCLGA1700

Max CPU Configuration		1

Thermal Solution Specification		PCG 2020C

TJUNCTION		100°C

Package Size		45.0 mm x 37.5 mm
